S-----------------------------Three-phase
B-----------------------------Copper foil LV coil
H-----------------------------Amorphous alloy core
16-----------------------------performance code
M -----------------------------Sealed type
□------------------------------rated capacity(KVA)
□------------------------------voltage class（KV）



General



   Over a century, principle of power transformer has not ever changed, but as time progressed, the advanced production facilities are getting perfected, the transformer with amorphous alloy core produced by our company adopts new magneto conductive material, i.e. amorphous alloy core. The no-load loss of this kind of transformer is 80% lower than that of stalloy cored transformer, and so does the no-load current. It is the most ideal distribution transformer in energy saving at present, especially suitable for the rural power grids and the developing districts, where the load factor is rather low. The amorphous alloy cored power transformer has advantage of low no-load loss, energy-saving and environment-protection, and it is fully in accordance with the national industrial policy” resource-saving, environmentally-friendly, and the establishment of reef society". The oil immersed transformer also has the ability to reduce the CO, SO, and NOx dioxide emissions of harmful gases. and therefore it is tiled as "green material" of 21st century.
